Features
● Display 6000 counts
● Jaw Opening Ф26mm/1.0"
● Auto Ranging
● Auto Power Off
● Non-Contact Voltage Detector
● Relative Measurement
● Diode Open Volatge 2.7V
● Continuity Buzzer <50±20Ω
● MAX/MIN
● Data Hold
● Display Backlight
● Work Light
● Low Battery Display
|
Specifications |
Range |
Resolution |
Accuracy |
|
DC Voltage |
600mV/6V/60V/600V |
0.1mV/0.001V/0.01V/1V |
±(0.7%+2) |
|
AC Voltage |
6V/60V |
0.001V/0.01V |
±(0.8%+3) |
|
600V |
1V |
±(1.0%+4) |
|
|
DC Current |
60A/600A |
0.01A/0.1A |
±(3.0%+6) |
|
AC Current |
60A/600A |
0.01A/0.1A |
±(2.5%+6) |
|
Resistance |
600Ω/6kΩ/60kΩ/600kΩ |
0.1Ω/0.001kΩ/0.01kΩ/0.1kΩ |
±(0.8%+3) |
|
6MΩ/60MΩ |
0.001MΩ/0.01MΩ |
±(1.2%+3) |
|
|
Capacitance |
40nF/400nF/4µF |
0.01nF/0.1nF/0.001µF |
±(4.0%+5) |
|
40µF/400µF/4000µF |
0.01µF/0.1µF/1µF |
±(4.0%+5) |
|
|
Frequency (A) |
100Hz/1kHz |
0.01Hz/0.1Hz |
±(1.5%+5) |
|
Frequency (V) |
100Hz/1kHz/10kHz |
0.01Hz/0.1Hz/0.001kHz |
±(1.5%+5) |
|
Frequency |
10Hz/100Hz/1kHz/10kHz |
0.001Hz/0.01Hz/0.1Hz/0.001kHz |
±(0.5%+3) |
|
(Hz/Duty) |
100kHz/1MHz/10MHz |
0.01kHz/0.1kHz/0.001MHz |
±(0.5%+3) |
|
Duty Cycle |
0.1%~99.9% |
0.10% |
±(3.0%+5) |
|
Temperature |
-20℃~0℃ |
1℃ |
±(3.0%+4) |
|
1℃~400℃ |
1℃ |
±(1.0%+3) |
|
|
401℃~1000℃ |
1℃ |
±(2.0%) |
|
|
-4℉~32℉ |
1℉ |
±(3.0%+7) |
|
|
33℉~752℉ |
1℉ |
±(1.0%+5) |
|
|
753℉~1832℉ |
1℉ |
±(2.0%) |
