Features
● Display 4000 counts
● Jaw Opening Ф24mm/0.9"
● Auto & Manual Ranging
● Auto Power Off
● Non-Contact Voltage Detector
● Diode Open Voltage 3.2V
● Continuity Buzzer <50Ω
● Data Hold
● Display Backlight
● Work Light
● Low Battery Display
|
Specifications |
Range |
Resolution |
Accuracy |
|
DC Voltage |
4V/40V/400V/600V |
1mV/10mV/0.1V/1V |
±(0.8%+3) |
|
AC Voltage |
4V/40V/400V/600V |
1mV/10mV/0.1V/1V |
±(1.0%+3) |
|
DC Current |
4A/40A/80A |
1mA/10mA/0.1A |
±(2.5%+5) |
|
AC Current |
4A/40A/80A |
1mA/10mA/0.1A |
±(2.5%+5) |
|
Resistance |
400Ω/4kΩ/40kΩ/400kΩ/4MΩ |
0.1Ω/1Ω/10Ω/0.1kΩ/1kΩ |
±(0.8%+3) |
|
40MΩ |
10kΩ |
±(1.2%+3) |
|
|
Capacitance |
4nF/40nF/400nF/4µF |
1pF/10pF/0.1nF/1nF |
±(4.0%+3) |
|
40µF/400µF/4mF/40mF |
10nF/0.1µF/1µF/10µF |
±(4.0%+3) |
|
|
Frequency (Clamp) |
100Hz/1kHz |
0.01Hz/0.1Hz |
±(1.5%+5) |
|
Frequency (Voltage) |
100Hz/1kHz/10kHz |
0.01Hz/0.1Hz/1Hz |
±(1.5%+5) |
|
Logic Frequency |
10Hz/100Hz/1kHz/10kHz |
0.001Hz/0.01Hz/0.1Hz/1Hz |
±(0.5%+3) |
|
100kHz/1MHz/10MHz |
0.01kHz/0.1kHz/1kHz |
±(0.5%+3) |
|
|
Duty Cycle |
0.5%~99.5% |
0.10% |
±(3.0%) |
|
Temperature |
-20℃~1000℃ |
1℃ |
±(3.0%+3) |
|
-4℉~1832℉ |
1℉ |
±(3.0%+3) |
