Features
● Display 6600 counts
● Jaw Opening Ф26mm/1.0"
● Auto & Manual Ranging
● Auto Power Off
● Inrush 100ms Current Integral
● True root mean square
● Diode Open Voltage 3.3V
● Continuity Buzzer <50±20Ω
● MAX/MIN Measurement
● Data Hold
● Display Backlight
● Work Light
● Low Battery Display
|
Specifications |
Range |
Resolution |
Accuracy |
|
DC Voltage |
660mV/6.6V/66V |
0.1mV/0.001V/0.01V |
±(0.8%+3) |
|
600V |
0.1V |
±(1.0%+5) |
|
|
AC Voltage |
660mV |
0.1mV |
±(1.5%+10) |
|
6.6V/66V |
0.001V/0.01V |
±(1.2%+5) |
|
|
600V |
0.1V |
±(1.5%+10) |
|
|
DC Current |
66A/600A |
0.01A/0.1A |
±(3.0%+10) |
|
AC Current |
66A/600A |
0.01A/0.1A |
±(3.0%+10) |
|
Inrush Current |
66A/600A |
0.01A/0.1A |
±(10.0%+60) |
|
Resistance |
660Ω/6.6kΩ/66kΩ |
0.1Ω/0.001kΩ/0.01kΩ |
±(1.2%+2) |
|
660kΩ/6.6MΩ |
0.1kΩ/0.001MΩ |
±(1.2%+2) |
|
|
66MΩ |
0.1MΩ |
±(2.0%+5) |
|
|
Capacitance |
6.6µF |
0.001μF |
±(4.0%+50) |
|
66µF/660µF/6.6mF/66mF |
0.01μF/0.1μF/0.001mF/0.01mF |
±(4.0%+3) |
|
|
Frequency (A) |
660Hz/1kHz |
0.1Hz/0.001kHz |
±(1.5%+5) |
|
>1kHz |
0.01kHz |
Referance |
|
|
Frequency (V) |
660Hz/6.6kHz/10kHz |
0.1Hz/0.001kHz/0.01kHz |
±(1.5%+5) |
|
>10kHz |
0.01kHz |
Referance |
|
|
Duty Cycle |
10%~95% |
0.10% |
±3.0% |
