Features
● Display 4000 counts
● Jaw Opening Ф40mm/1.6"
● Auto & Manual Ranging
● Auto Power Off
● Diode Open Voltage 2.8V
● Continuity Buzzer <50±20Ω
● Relative Measurement
● Data Hold
● Low Battery Display
● Display Backlight
● Work Light
● Bar Graph
|
Specifications |
Range |
Resolution |
Accuracy |
|
DC Voltage |
400mV |
0.1mV |
±(1.0%+2) |
|
4V/40V/400V |
0.001V/0.01V/0.1V |
±(0.7%+2) |
|
|
600V |
1V |
±(0.8%+2) |
|
|
AC Voltage |
400mV/4V/40V/400V |
0.0001V/0.001V/0.01V/0.1V |
±(0.8%+3) |
|
600V |
1V |
±(1.0%+4) |
|
|
DC Current |
40A/400A/1000A |
0.01A/0.1A/1A |
±(3.0%+6) |
|
AC Current |
40A/400A/1000A |
0.01A/0.1A/1A |
±(2.5%+6) |
|
Resistance |
400Ω/4kΩ/40kΩ/400kΩ |
0.1Ω/0.001kΩ/0.01kΩ/0.1kΩ |
±(0.8%+3) |
|
4MΩ/40MΩ |
0.001MkΩ/0.1MΩ |
±(1.2%+3) |
|
|
Capacitance |
40nF/400nF/4μF |
0.01nF/0.1nF/0.001μF |
±(4.0%+5) |
|
40μF/400μF/4000μF |
0.01μF/0.1μF/1μF |
±(4.0%+5) |
|
|
Frequency |
100Hz/1kHz |
0.01Hz/0.1Hz |
±(1.5%+5) |
|
>1kHz |
0.001kHz |
Reference |
|
|
Frequency |
100Hz/1kHz/10kHz |
0.01Hz/0.1Hz/0.001kHz |
±(1.5%+5) |
|
>10kHz |
0.01kHz |
Reference |
|
|
Frequency |
10Hz/100Hz/1kHz/10kHz |
0.001Hz/0.01Hz/0.1Hz/1Hz |
±(0.5%+2) |
|
100kHz/1MHz/10MHz |
0.01kHz/0.1kHz/0.001MHz |
±(0.5%+2) |
|
|
Duty Cycle |
0.1%~99% |
0.10% |
±3.0% |
