Features
● Display 4000 counts
● Jaw Opening Ф40mm/1.6"
● Auto & Manual Ranging
● Auto Power Off
● Diode Open Voltage 2.8V
● Continuity Buzzer <50±20Ω
● Relative Measurement
● Data Hold
● Low Battery Display
● Display Backlight
● Work Light
● Bar Graph
● True Root Mean Square
Specifications | Range | Resolution | Accuracy |
DC Voltage | 400mV | 0.1mV | ±(1.0%+2) |
4V/40V/400V | 0.001V/0.01V/0.1V | ±(0.7%+2) | |
600V | 1V | ±(0.8%+2) | |
AC Voltage | 400mV/4V/40V/400V | 0.0001V/0.001V/0.01V/0.1V | ±(0.8%+3) |
600V | 1V | ±(1.0%+4) | |
DC Current | 40A/400A/1000A | 0.01A/0.1A/1A | ±(3.0%+6) |
AC Current | 40A/400A/1000A | 0.01A/0.1A/1A | ±(2.5%+6) |
Resistance | 400Ω/4kΩ/40kΩ/400kΩ | 0.1Ω/0.001kΩ/0.01kΩ/0.1kΩ | ±(0.8%+3) |
4MΩ/40MΩ | 0.001MkΩ/0.1MΩ | ±(1.2%+3) | |
Capacitance | 40nF/400nF/4μF | 0.01nF/0.1nF/0.001μF | ±(4.0%+5) |
40μF/400μF/4000μF | 0.01μF/0.1μF/1μF | ±(4.0%+5) | |
Frequency (A) | 100Hz/1kHz | 0.01Hz/0.1Hz | ±(1.5%+5) |
>1kHz | 0.001kHz | Reference | |
Frequency (V) | 100Hz/1kHz/10kHz | 0.01Hz/0.1Hz/0.001kHz | ±(1.5%+5) |
>10kHz | 0.01kHz | Reference | |
Frequency | 10Hz/100Hz/1kHz/10kHz | 0.001Hz/0.01Hz/0.1Hz/1Hz | ±(0.5%+2) |
(Hz/Duty) | 100kHz/1MHz/10MHz | 0.01kHz/0.1kHz/0.001MHz | ±(0.5%+2) |
Duty Cycle | 0.1%~99% | 0.10% | ±3.0% |
