Bút Đo Độ Dẫn Hanna HI98309
Model: HI98309
Hãng sản xuất: HANNA
Xuất xứ: RUMANI
Bảo hành: 6 tháng
Thông số kỹ thuật:
Thang đo: 0.000 to 1.999 µS/cm
Độ phân giải: 0.001 µS/cm
Độ chính xác: ±2% F.S
Hiệu chuẩn: nhà máy
Bù nhiệt: tự động từ 0 to 50°C (32 to 122°F) với β=2%/°C điển hình
Pin: 4 pin 1.5V
Môi trường: 0 to 50°C (32 to 122°F); RH max 95% không ngưng tụ
Kích thước: 175 x 41 x 23 mm (6.9 x 1.6 x 0.9’’)
Khối lượng: 95 g (3.4 oz.)
Cung cấp gồm: HI98309 được cung cấp với nắp bảo vệ, pin và hướng dẫn.
TÍNH NĂNG NỔI BẬT Bút Đo Độ Dẫn Hanna HI98309
- Hiệu chuẩn nhà máy
- Đầu dò nhiệt độ tiếp xúc: phản ứng nhanh khi thay đổi nhiệt độ mẫu
- Bù nhiệt tự động (ATC)
- Bút Đo Độ Dẫn Hanna HI98309 Điện cực than chì: giảm hiệu ứng phân cực
HI98309
Ultra Pure Water (UPW) Tester
Details
The HI98309 uses a conductometric measurement to determine the purity of water. The HI98309 Ultra Pure Water tester (UPW) enables users to check the purity of water, best suited for electronics and semiconductor industries. This tester is housed in durable casing that provides excellent protection against harsh industrial environments.
The HI98309 features an amperometric graphite electrode that provides better repeatability in measurements, since they do not oxidize. An amperometric measurement of EC is based on Ohm’s Law, I = V/R, where R depends on the distance between two pins and their surface. Oxidation changes both the distance and surface, which will affect accuracy. The non-oxidizing graphite pins are able to provide an optimal surface for accurate, dependable results. When calibration is needed, simply submerge the electrode tip into calibration solution and adjust the trimmer on the side of the tester.
Electrolytic conductivity, abbreviated as EC, is a measurement made in which electrical charges on atomic or larger sized particles in a medium are moved under the influence of a potential difference. EC is a measure of concentration however it is non-specic for ion type. An ion is a charged particle present in the solution that contributes to the current flow. Ions are formed when a salt such as sodium chloride is dissolved in water to form particles having electrical charges. Sodium chloride, separates into Na+ and Cl-. This is a simplified denfinition for the measurement is affected by many things such as the type of ionic compound(s) dissolved in the water; the ions mobility, the solution viscosity, temperature as well as concentration.
Electrical conductance, the ability of a substance to conduct an electrical current is the reciprocal of electrical resistance. “Conductance” and “Resistance” depend on the geometrical dimensions of the substance being measured. Conductivity and resistivity are “normalized” terms that are used to denote a bulk intrinsic property of a substance. This is the measurement a standardized EC probe on a Conductivity or resistivity meter provides. Conductivity measurements can be used to provide additional industry specific measurements; TDS, Salinity and USP compliant conductivity. Many of Hanna’s meters provide these measurements also.
EC/TDS
| EC Range | 0.000 to 1.999 µS/cm |
|---|---|
| EC Resolution | 0.001 µS/cm |
| EC Accuracy | ±2% F.S. |
| EC Calibration | Factory calibrated |
General Meter
| Battery Type / Life | 1.5V (4) / approximately 200 hours of continuous use |
|---|---|
| Environment | 0 to 50°C (32 to 122°F); RH max 95% non-condensing |
| Dimensions | 175 x 41 x 23 mm (6.9 x 1.6 x 0.9’’) |
| Weight | 95 g (3.4 oz.) |
| Ordering Information | HI98309 is supplied with protective cap, batteries and instructions. |
| Warranty | 1 year |
