Delmhorst offers a wide assortment of electrodes known throughout the industry for their durability. All Delmhorst electrodes fit any Delmhorst moisture meter. Below are electrodes that are typically used for this model:
Double roller type for measuring moisture content on a moving web.
Pin type, with two rows of four pins each, maximum penetration 1/8". Penetration can be adjusted according to stock thickness by means of gauge block.
Blade type electrode for measuring of paper on skids. Blades are 5" long. Longer blades available on special order.
Fitted with the same 5/16" penetration pins that are mounted on our pin type meters. This electrode is great for a variety of different applications:
- Home inspector: use on wood joists and drywall.
- Paper producer: use on curved surfaces such as cardboard and paper tubes.
- Woodworker: use on timber, poles, and veneer/
2-E is also available as the 2- ET with a tapped handle for hard to reach areas. Can also be fitted with A-103 uninsulated pins with 1 3/32” length and 11/16” penetration.
Clamp type for testing thin sheet stock. The sample tested is compressed between two smooth discs.
Leaf type for measuring moisture content on a moving web or roll. Can be used with a portable unit or for stationary installation.
Prods for testing standard and high density bales (requires H-4 Handle).
- 830-2 – 10” prod
- 830-3 – 18” prod
- 830-4 – 36” prod
- 830-5 – 12” for hops
Electrode handle that attaches to the built-in connector on the top of any moisture meter. Can be used with the 830 series prods, 831 short pin disc shaped prod, and 832 long pin disc shaped prod. This is useful for large or high density bales of hay or scrap paper. Two handed operation is recommended over using a prod that connects directly to the top of the meter (like our 1235 series) to minimize stress placed on the meter casing.
