Máy đo lực điện tử IMADA DST-2N
Model: DST-2K
Hãng sản xuất: IMADA-JAPAN
Xuất xứ: Nhật Bản
Bảo hành: 12 tháng
Thông số kỹ thuật:
Giải đo [Max]: 2N
Độ phân giải: 0,001N
Đơn vị đo: N
Chức năng: Peak hold,Real-time
Độ chính xác: +/-0.2%
Giao tiếp: USB,RS232
Nhiệt độ hoạt động: 0 – 40°C
Trọng lượng máy: 460g
Kích thước: 181x72x32mm
Máy đo lực điện tử IMADA DST-2N Phụ kiện: Hộp đựng,hướng dẫn sử dụng,6 loại đầu móc,giấy chứng nhận kiểm thử
Máy đo lực điện tử IMADA DST-2N
DST Digital Force Gauge
Easy-to-use basic force gauge with large backlit LCD display
Standard Features
Imada DST digital force gauges are simple-to-use basic gauges featuring user-friendly menu operation. Selections including unit and measuring mode can be locked to prevent accidental changes.
The large backlit LCD display can be configured in basic format to show value, unit and measuring mode or multi-line format to display peak and real time values simultaneously. Additional features include reversible display and high/low setpoints with OK indicator for Go/No Go testing.
The gauges have a 30,000/sec ultra-high sampling rate. Collect the data via USB or RS-232 connections with the optional Force Logger or SW-1X software.
DST gauges are powered by rechargeable Ni-MH batteries or the AC adapter/charger. The batteries are user replaceable and can also be charged using USB ports or USB portable chargers.
All DST gauges are sold as kits complete with gauge, carrying case, six attachments and AC adapter/charger.
| Model | DST |
|---|---|
| Accuracy | ±0.2％F.S 1digit |
| Unit | N(mN,kN) , kg(g), lbf （*1） |
| Display | Signed 4-digit LCD |
| Sampling rate | Max. 1000 data / sec (1000Hz) |
| Battery | Approx.30 hours (when back light is off) Approx. 14 hours (when back light is on) (*needs 4.5 hours for full charge) |
| Overload | Approx. 200％F.S. |
| Power | Nickel-Metal Hydride battery (NiMH battery), USB charge (PC, mobile battery, AC adapter) |
| Operating environment | Temperature：0 – 40℃ Humidity：20 – 80％RH |
| Function | Peak hold(Tensile or compression)/Comparator(OK Judgement)/Sensitivity(3 steps)/Reversible display /Sign inversion/Setting lock/Date & Time/Off timer (Auto power-off)/Reminder for calibration schedule/Overload alarm |
| Output | USB/RS232C |
| Overload alarm | Alarm to notify “near-overload state”: Approx.90%F.S. (Alarm sound) Alarm to notify “overloaded state”: Approx.110%F.S. (Alarm sound/Indication blinking) |
| Weight | Approx.460ｇ （*2） |
| Dimensions | Refer to Dimensions below. |
| Accessory | Force Logger(Data capturing software)／USB cable／ ACAdapter／Attachment（*3）／Carrying case／Instruction manual／Inspection certificate |
*1 These are the specifications for International model. Note that the available units are different from Japanese domestic model and international one. kN is available at 1000N, mN and gf is available at 2N and 5N ranges.
*2 The weight is slightly different by the models.
*3 For further information, refer to “Accessory attachments” in “Models for DSV series force gauges” below.
| Model | Capacity | Display | Resolution | Thread | Accessory attachments |
|---|---|---|---|---|---|
| DST-2N | 2N | 2.000N | 0.001N | M6 | A1-A6 |
| DST-5N | 5N | 5.000N | 0.001N | ||
| DST-20N | 20N | 20.00N | 0.01N | ||
| DST-50N | 50N | 50.00N | 0.01N | ||
| DST-200N | 200N | 200.0N | 0.1N | S1-S6 | |
| DST-500N | 500N | 500.0N | 0.1N | ||
| DST-1000N | 1000N | 1000N | 1N | SR1-S6 |
