Máy đo lực điện tử IMADA ZTA-50N (50N/0,01N)

Model: ZTA-50N
Hãng sản xuất: IMADA
Xuất xứ: Japan
Bảo hành: 12 tháng
Liên hệ
Tình trạng: Còn hàng
Điện thoại: 0976595968

Model: ZTA-50N
Hãng sản xuất: IMADA-JAPAN
Xuất xứ: Nhật Bản
Bảo hành: 12 tháng
Thông số kỹ thuật:
Giải đo [Max]: 50N
Độ phân giải: 0,01N
Đơn vị đo:N
Độ chính xác: +/-0.2%
Pin: 8 giờ hoạt động, 2 giờ sạc
Giao tiếp: RS232 ,USB
Nhiệt độ hoạt động: 0 – 40°C
Trọng lượng máy: 490 g
Kích thước: 191x75x34mm
Phụ kiện: Hộp đựng,hướng dẫn sử dụng,cáp USB,Adapter AC,đĩa CD



Specifications for High Functionality Model Digital Force Gauge ZTA series

Model ZTA
Feature Advanced model with various functions such as data saving in USB memory stick, displacement I/O and more.
Accuracy +/-0.2%F.S.+/-1digit
Unit of measurement (*1) N, kgf, lbf (*2)
Display 4-digit Organic EL
Display update 16 / sec
Sampling rate 2000 data / sec at maximum (*3)
Battery 8 hours (2 hours charge) (*4)
Safe overload rating Approx.200%F.S.
Operating environment Temperature: 0 to +40 degree Celsius, Humidity: 20 to 80%RH
Function Customized display (header and footer), Peak hold (tension and compression),
Internal 1000 points data memory, Comparator (judgment of OK or NG),
Reversible display, Sign inversion, Zero clear timer, +NG alarm, Off timer (auto power off),
Dumping,Time display, 1st/2nd peak,Displacement detection at force peak value,
Displacement zero reset at selected force, setting lock
Output USB, RS232C, Mitutoyo digimatic (*5), 2 VDC analog output (D/A),
Comparator 3 steps (-NG/OK/+NG), Overload alarm,
Sub comparator 2 steps (output of large or small judgment), USB flash drive, Displacement.
Overload warning Approx.110%F.S. (Warning message and alarm )
External connecting switch SEND (a point of contact holding), Zero reset, Peak ON/OFF setting
Available linear scales (*6) – Online driver output (a line receiver according to RS422/485 must be built in.)
– Open collector output (Voltage drop between contacts must be smaller than 0.5V.
Weight Approx.490g (*7)
Dimensions Please refer to dimensions.
Accessory(*6) AC adapter, Inspection certificate, CD driver (including simple software for data logging),
Attachments (The set of attachments varies according to range.),
USB cable,Carrying case, Adaptor for USB flash drive. (*8)

*1 These are the specifications for International model.  Please note that this unit is different from Japanese domestic model and international one.
*2 [N indication] The indication of 2N and 5N models is mN or N. The indication of 1000N,2500N and 5000N model is N or kN.
[kgf indication] The indication of 2N and 5N models is gf.
[lbf indication] The indication of 2N and 5N models is ozf.
*3 Up to 100 data/sec. is saved in USB memory (selectable among 1, 50, and 100 /sec)
*4 The battery is more consumed when connected to USB flash drive or a linear scale.
*5 Not always available for Mitutoyo digimatic products.
*6 Some linear scales could not be available even if they meet the mentioned specifications.
*7 Weight is slightly different according to range.
*8 USB flash drive is not included.



Model List for High Functionality Model Digital Force Gauge ZTA series

Model Range Display Resolution Thread
ZTA-2N 2N (200gf) 2.000N/2000mN (200.0gf) 0.001N/1mN (0.1gf) M6
ZTA-5N 5N (500gf) 5.000N/5000mN (500.0gf) 0.001N/1mN (0.1gf)
ZTA-20N 20N (2kgf) 20.00N (2.000kgf) 0.01N (0.001kgf)
ZTA-50N 50N (5kgf) 50.00N (5.000kgf) 0.01N (0.001kgf)
ZTA-100N 100N (10kgf) 100.0N (10.00kgf) 0.1N (0.01kgf)
ZTA-200N 200N (20kgf) 200.0N (20.00kgf) 0.1N (0.01kgf)
ZTA-500N 500N (50kgf) 500.0N (50.00kgf) 0.1N (0.01kgf)
ZTA-1000N 1000N (100kgf) 1000N/1.000kN (100.0kgf) 1N/0.001kN (0.1kgf)
