Máy phân tích công suất Hioki PW3336-02
Model:PW3336-02
Hãng sản xuất: HIOKI
Xuất xứ: Japan
Bảo hành: 12 Tháng
Thông số kỹ thuật:
Đo lường:
- 1-phase 2-dây, 1-phase 3-dây
- 3-phase 3-dây, 3phase 4-dây
- 4 kênh đo điện áp, 4 kênh đo dòng điện
Các nhóm đo lường:
- Điện áp, dòng điện, công suất tiêu thụ/phản kháng/biểu kiến
- Công suất tiêu thụ/phản kháng tổng hợp
- Hệ số công suất, tần số, dạng sóng hài
Thang đo:
- Điện áp: AC/DC 15 V đến 1000 V, 7 ranges
- Dòng điện: AC/DC 200 mA đến 50 A, 8 ranges
- Công suất: 3.0000 W đến 150.00 kW
Độ chính xác(Công suất hữu công):
- ±0.1% rdg. ±0.1% f.s. (DC)
- ±0.1% rdg. ±0.05% f.s. (45 Hz to 66 Hz, at Input < 50% f.s.)
- ±0.15% rdg. (45 Hz to 66 Hz, at 50% f.s. ≤ Input)
Chức năng khác:
- AC+DC, AC+DC Umn, AC, DC, FND
- Tự động chuyển phạm vi đo, giá trị trung bình
- Thiết lập tỷ lệ VT or CT, kiểm soát sự đồng bộ
- MAX/ MIN, và những tính năng khác
Giao tiếp thiết bị bên ngoài: RS-232C, GP-IB, LAN standard
Nguồn: 100 to 240 V AC, 50/60 Hz, 40 VA max
Kích thức sản phẩm: 305*132*256mm
Khối lượng sản phẩm: 5.6 kg
Phụ kiện đi kèm: Hướng dẫn sử dụng ×1, Hướng dẫn đo ×1, Dây nguồn ×1.
Máy phân tích công suất Hioki PW3336-02
POWER METER PW3336
2-Channel AC/DC Power Meter for Single-Phase to 3P3W Equipment such as Motors, Inverters, Power Conditioners, and Power Supplies.
| Measurement lines | Single-phase 2-wires, single-phase 3-wires, 3-phase 3-wires, (voltage / current measurement range set for each wiring mode) |
|---|---|
| Measurement items | Voltage, Current, Active power, Apparent power, Reactive power, Power factor, Phase angle, Frequency, Efficiency, Current integration, Active power integration, Integrated time, Voltage waveform peak value, Current waveform peak value, Voltage crest factor, Current crest factor, Time average current, Time average active power, Voltage ripple factor, Current ripple factor |
| Harmonic parameters | Synchronization frequency range: 10 Hz to 640 Hz, Analysis order up to 50th Harmonic voltage RMS value, Harmonic current RMS value, Harmonic active power, Total harmonic voltage distortion, Total harmonic current distortion, Voltage fundamental waveform, Current fundamental waveform, Active power fundamental waveform, Apparent power fundamental waveform, Reactive power fundamental waveform, Power factor fundamental waveform (displacement power factor), Voltage current phase difference fundamental waveform, Interchannel voltage fundamental wave phase difference, Interchannel current fundamental wave phase difference, Harmonic voltage content % , Harmonic current content % , Harmonic active power content % (The following parameters can be downloaded as data during PC communication but not displayed: Harmonic voltage phase angle, Harmonic current phase angle, Harmonic voltage current phase difference) |
| Measurement range | Voltage : AC/DC 15 V to 1000 V, 7 ranges Current : AC/DC 200 mA to 50 A, 8 ranges Power : 3.0000 W to 100.00 kW (Depends on combination of voltage and current range) |
| Integration measurement (Integration time up to 10,000 hours) | [Current] No.of displayed digits: 6 digits (from 0.00000 mAh, Polarity-independent integration and Sum value) [Active power] No.of displayed digits: 6 digits (from 0.00000 mWh, Polarity-independent integration and Sum value) |
| Input resistance (50/60 Hz) | [Voltage] 2 MΩ, [Current] 1 mΩ or less (direct input) |
| Basic accuracy (Active power) | ±0.1% rdg. ±0.1% f.s. (DC) ±0.1% rdg. ±0.05% f.s. (45 Hz to 66 Hz, at Input < 50% f.s.) ±0.15% rdg. (45 Hz to 66 Hz, at 50% f.s. ≤ Input) |
| Display refresh rate | 5 times/s to 20 seconds (depend on average times settings) |
| Frequency characteristics | DC, 0.1 Hz to 100 kHz |
| D/A output (-02/-03 model only) | 16 channels (selectable from following items), Level output DC ±2 V, Waveform output 1 V f.s. Level output, instantaneous waveform output (voltage, current, active power) Level output (apparent power, reactive power, power factor, or other) High-speed active power level output |
| Functions | [Rectification method] AC+DC, AC+DC Umn, AC, DC, FND, Auto-range, Average, VT or CT ratio settings, Synchronized control, MAX/MIN, or other functions |
| Interfaces | RS-232C / LAN standard, (-01/-03 model also includes GP-IB) |
| Power supply | 100 to 240 V AC, 50/60 Hz, 40 VA max. |
| Dimensions and mass | 305 mm (12.01 in) W × 132 mm (5.20 in) H × 256 mm (10.08 in) D, 5.2 kg (183.4 oz) |
| Accessories | Instruction manual ×1, Measurement guide ×1, Power cord ×1 |
Current measurement
Can be connected to the current sensor input terminals (1 sensor necessary for single-phase measurement, and 2 or 3 sensors required for 3-phase measurements)
CLAMP ON SENSOR 9660
• 40Hz to 5kHz • 100 A AC rated input • φ 15 mm (0.59 in) core dia.
CLAMP ON SENSOR 9661
• 40Hz to 5kHz • 500 A AC rated input • φ 46 mm (1.81 in) core dia.
CLAMP ON SENSOR 9669
• 40Hz to 5kHz • 1000 A AC rated input • φ 55 mm (2.17 in) Core dia.
AC FLEXIBLE CURRENT SENSOR CT9667
• 10 Hz to 20 kHz (±3dB) • 5000 A/ 500 A AC rated input
Up to 200 A (High precision)
*To use a high precision current sensor (-05 model), requires Sensor Unit CT9555 and Connection Cord L9217.
*To use a high precision current sensor (without “-05” model), requires Conversion Cable CT9900 for PL23 (10 pin) to ME15W (12 pin) conversion, Sensor Unit CT9555 and Connection Cord L9217.
*1 sensor necessary for single-phase measurement, 2 or 3 sensors required for 3-phase measurements. The same number of power supply and connection cord as the sensor is necessary.
AC/DC CURRENT SENSOR CT6863-05
• DC to 500kHz (Phase: up to 300kHz) • Rated 200A AC/DC • φ 24 mm (0.94 in) core dia.
AC/DC CURRENT PROBE CT6841-05
• DC to 1MHz (Phase: up to 300kHz) • Rated 20A AC/DC • φ 20 mm (0.79 in) core dia.
AC/DC CURRENT PROBE CT6843-05
• DC to 500kHz (Phase: up to 300kHz) • Rated 200A AC/DC • φ 20 mm (0.79 in) core dia.
AC/DC CURRENT SENSOR CT6862-05
• DC to 1MHz (Phase: up to 300kHz) • Rated 50A AC/DC • φ 24 mm (0.94 in) core dia.
CLAMP ON SENSOR 9272-05
• 1Hz to 100kHz (Phase: 5Hz to 50kHz) • Rated 20A/200A AC/DC • φ 46 mm (1.81 in) core dia.
Up to 500 A (High precision)
*To use a high precision current sensor (-05 model), requires Sensor Unit CT9555 and Connection Cord L9217.
*To use a high precision current sensor (without “-05” model), requires Conversion Cable CT9900 for PL23 (10 pin) to ME15W (12 pin) conversion, Sensor Unit CT9555 and Connection Cord L9217.
*1 sensor necessary for single-phase measurement, 2 or 3 sensors required for 3-phase measurements. The same number of power supply and connection cord as the sensor is necessary.
AC/DC CURRENT SENSOR 9709-05
• DC to 100kHz (Phase: up to 100kHz) • Rated 500A AC/DC • φ 36 mm (1.42 in) core dia.
AC/DC CURRENT PROBE CT6844-05
• DC to 200kHz (Phase: up to 200kHz) • Rated 500A AC/DC • φ 20 mm (0.79 in) core dia.
AC/DC CURRENT PROBE CT6845-05
• DC to 100kHz (Phase: up to 100kHz) • Rated 500A AC/DC • φ 50 mm (1.97 in) core dia.
AC/DC CURRENT SENSOR CT6904
• DC to 4 MHz (Phase: up to 1 MHz) • Rated 500A AC/DC • φ 32 mm (1.26 in) core dia.
AC/DC CURRENT SENSOR CT6875
• DC to 2MHz (Phase: up to 1MHz) • Rated 500A AC/DC • φ 36 mm (1.42 in) core dia.
Up to 1000 A (High precision)
*To use a high precision current sensor (-05 model), requires Sensor Unit CT9555 and Connection Cord L9217.
*To use a high precision current sensor (without “-05” model), requires Conversion Cable CT9900 for PL23 (10 pin) to ME15W (12 pin) conversion, Sensor Unit CT9555 and Connection Cord L9217.
*1 sensor necessary for single-phase measurement, 2 or 3 sensors required for 3-phase measurements. The same number of power supply and connection cord as the sensor is necessary.
AC/DC CURRENT SENSOR CT6865-05
• DC to 20kHz (Phase: up to 1kHz) • Rated 1000A AC/DC • φ 36 mm (1.42 in) core dia.
AC/DC CURRENT PROBE CT6846-05
• DC to 20kHz (Phase: up to 20kHz) • Rated 1000A AC/DC • φ 50 mm (1.79 in) core dia.
AC/DC CURRENT SENSOR CT6876
• DC to 1.5MHz (Phase: up to 1MHz) • Rated 1000A AC/DC • φ 36 mm (1.42 in) core dia.
PL23 (10 pin) - ME15W (12 pin) conversion
*When using a PL23 terminal sensor without “-05” in the model number, Conversion Cable CT9900 must be used to connect to ME15W terminal.
*When using the CT6865 and CT6846 (without “-05”), connection via the CT9900 and manual settings are required on the main device.
CONVERSION CABLE CT9900
Convert PL23 (10-pin) terminal to ME15W (12-pin) terminal
Power supply for sensors
CONNECTION CORD L9217
Cord has insulated BNC connectors at both ends, 1.6 m (5.25 ft) length
SENSOR UNIT CT9555
• Power supply for current sensors when used alone • 1ch, with waveform output
PC communications
GP-IB CONNECTOR CABLE 9151-02
2 m (6.56 ft) length
RS-232C CABLE 9637
9 pin - 9 pin, cross, 1.8 m (5.91 ft) length
LAN CABLE 9642
Straight Ethernet cable, supplied with straight to cross conversion adapter, 5 m (16.41 ft) length
Other options
Synchronize multiple units
CONNECTION CORD 9165
Cord has metallic BNC connectors at both ends, use at metallic terminal, 1.5 m (4.92 ft) length.
